TM 5-4320-216-20P
pearances of the same item will have the letters "REF"
Code
Explanation
in the applicable allowance column. To locate the
R Repair parts and assemblies which are
referenced item, locate the FSN or reference number in
economically reparable at DSU and GSU
the index. The earliest figure and item number is the
activities and are normally furnished by supply
referenced item. Items authorized for use as required
on an exchange basis.
but riot for initial stockage are identified with an asterisk
S Repair parts and assemblies which are
in the allowance column.
economically reparable at DSU and GSU
(2) The quantitative allowance for organizational
activities and which normally furnished by
level of maintenance represents one initial prescribed
supply on an exchange basis. When items
load for a 15-day period for the number of equipments
are determined by A GSU to be
supported. Units authorized additional prescribed loads,
uneconomically reparable, they will be
multiply the number 'of prescribed loads by the quantity
evacuated to a depot for evaluation and
in the appropriate density column to determine the
analysis before final disposition.
number of repair parts authorized.
T High dollar value recoverable repair parts which
are subject to special handling and are issued
(3) To determine allowances when supporting more
on an exchange basis. Such repair parts
than 100 of these. equipments: First, divide the number
normally are repaired or overhauled at depot
of equipments supported by 100 by moving the decimal
maintenance activities.
two spaces left; second, multiply the result by the
quantity in the 51-100 density column.
Example,
U
Repair parts specifically selected for salvage by
authorized allowance for 51-100 equipment'is 40; for
reclamation units because of precious metal
150 equipments, multiply 40 by 1.50 or 60 parts
content, critical materials, or high dollar value
authorized.
reusable casings or castings.
(4) Subsequent changes to allowances will be
b. Federal Stock Number. This column indicates
limited as follows: No change in the range of items is
authorized.
If additional items are considered
the Federal stock number assigned to the item and will
necessary, recommendation should be forwarded to
be used for requisitioning purposes.
c. Description. This column indicates the Federal
U.S. Army Mobility Equipment Command for exception
or. revision to the allowance list. Revisions to the range
item name and any additional description of the item
of items authorized will be made by the U. S. Army
required. Assembly components and subassemblies are
Mobility Equipment Command based upon engineering
indented under major assemblies. The abbreviation
experience, demand data, or TAERS information.
"w/e", when used as part of the nomenclature, indicates
the Federal stock number includes all armament,
g. Illustration. This column is divided as follows:
equipment, accessories, and repair parts issued with the
(1) Figure number.
Indicates the figure
item. A part number or other reference number is
number of the illustration in which the item is shown.
followed by the applicable five-digit Federal supply code
for manufacturers in parenthesis.
Repair parts
(2) Item number. Indicates the callout number
quantities included in kits and sets are shown in front of
the repair part name. Material required for manufacture
used to reference the item in the illustration.
or fabrication is identified.
d. Unit of Measure (U/M).
4. Special Information
A two-character
a. Identifications of the usable on codes included
alphabetic abbreviation indicating the amount or
quantity of the item upon which the allowances are
in the description columns of this publication are:
Code
Used on
based, e.g., ft, ea, pr, etc.
e. Quantity Incorporated in Unit. This column
A -------------Pump, Carver Model 4 WHIS
indicates the quantity of the item used in the assembly
B -------------Pump, Carver Model 4 WHISA
group. A "V" appearing in this column in lieu of a
quantity indicates that a definite quantity cannot be
Repair parts not symbolized are applicable to all end
indicated (e.g., shims, spacers, etc.).
items covered in this manual.
f
Fifteen-Day Organizational Maintenance
Allowance.
(1) The allowance columns are divided into four
subcolumns. Indicated in each subcolumn opposite the
first appearance of each item is the total quantity of
items authorized for the number of equipments
supported. Subsequent ap
iv
